AIR-CAP2702I-C-K9

AIR-CAP2702I-C-K9

Артикул:
₴ 37,881.00
Cisco Aironet 2700 Series Access Points with Internal antennas
Модель: AIR-CAP2702I-C-K9
Виробник: Cisco
Наявність:В наявності

Опис Created with Pixso.

AIR-CAP2702I-C-K9 Specifications

Devide Type

Wireless  Access point

Regulatory domain

C regulatory domain

Supported wireless LAN controllers

 ● Cisco 2500 Series Wireless Controllers
● Cisco Wireless Controller Module for ISR G2
● Cisco Wireless Services Module 2 (WiSM2) for Catalyst 6500 Series Switches
● Cisco 5500 Series Wireless Controllers
● Cisco Flex 7500 Series Wireless Controllers
● Cisco 8500 Series Wireless Controllers, Cisco Virtual Wireless Controller
● Cisco 5760 Wireless LAN Controller
● Cisco Catalyst 3850 Series Switches
● Cisco Catalyst 3650 Series Switches

Software

Cisco Unified Wireless Network Software Release 7.6MR2 or later

Data rates supported

 ● 802.11a: up to 54 Mbps
● 802.11g: up to 54 Mbps
● 802.11n on 2.4 GHz: up to 216.7 Mbps
● 802.11ac on 5 GHz: up to 1.3Gbps

Maximum number of nonoverlapping channels

5 GHz
●  802.11a:
◦   20 MHz: 21
●  802.11n:
◦   20 MHz: 21
◦   40 MHz: 9
●  802.11ac:
◦   20 MHz: 21
◦   40 MHz: 9
◦   80 MHz: 4

2.4 GHz
●  802.11b/g:
◦   20 MHz: 3
●  802.11n:
◦   20 MHz: 3

Antenna (purchase separately)
  • Certified for use with antenna gains up to 6 dBi (2.4 GHz and 5 GHz)
  • Cisco offers the industry's broadest selection of antennas, delivering optimal coverage for a variety of deployment scenarios

Interfaces
  • 10/100/1000BASE-T autosensing (RJ-45)
  • Management console port (RJ-45)

System memory
  • 512 MB DRAM
  • 64 MB flash

Power consumption

15 Watts

IEEE standards
  • IEEE 802.11a/b/g, 802.11n, 802.11h, 802.11d
  • IEEE 802.11ac Draft 5

Security

 ● 802.11i, Wi-Fi Protected Access 2 (WPA2), WPA
● 802.1X
● Advanced Encryption Standards (AES), Temporal Key Integrity Protocol (TKIP)

Extensible Authentication Protocol (EAP) types

 ● EAP-Transport Layer Security (TLS)
● EAP-Tunneled TLS (TTLS) or Microsoft Challenge Handshake Authentication Protocol Version 2 (MSCHAPv2)
● Protected EAP (PEAP) v0 or EAP-MSCHAPv2
● EAP-Flexible Authentication via Secure Tunneling (FAST)
● PEAP v1 or EAP-Generic Token Card (GTC)
● EAP-Subscriber Identity Module (SIM)

Frequency band and 20-MHz operating channels

C (C regulatory domain):
●  2.412 to 2.472 GHz; 13 channels
●  5.745 to 5.825 GHz; 5 channels

Environmental

 ● Nonoperating (storage) temperature: -22° to 158°F (-30° to 70°C)
● Nonoperating (storage) altitude test: 25˚C, 15,000 ft.
● Operating temperature: -4° to 122°F (-20° to 50°C)
● Operating humidity: 10% to 90% percent (noncondensing)
●  Operating altitude test: 40˚C, 9843 ft.
