AIR-ANT5180V-N
Артикул:
₴ 18,837.00
4900-5850 MHz, 8.0 dBi Omni with N Connect
The Cisco AIR-ANT5180V-N is a high-performance outdoor antenna designed to provide reliable and efficient wireless coverage in the 4900-5850 MHz frequency range. With a robust gain of 8.0 dBi, this omni-directional antenna features an N-Type connector for easy integration and exceptional connectivity. Ideal for various wireless LAN applications, the AIR-ANT5180V-N ensures extended coverage and superior signal quality in demanding outdoor environments.
AIR-ANT5180V-N Specifications | |
| Brand | Cisco |
| Model | AIR-ANT5180V-N |
| Frequency Range | 4900-5850 MHz |
| Antenna Type | Omni |
| Gain | 8.0 dBi |
| Connector Type | N Connect |
| Polarization | Linear, Vertical |
| Impedance | 50 Ohms nominal |
| VSWR | 2.0:1 or less |
| Radiation Pattern | 360 degrees (omni-directional) |
| Maximum Power | 50 watts |
| Operating Temperature | -40��C to 70��C (-40��F to 158��F) |
| Storage Temperature | -40��C to 85��C (-40��F to 185��F) |
| Operating Humidity | 0% to 100% (non-condensing) |
| Length | 31.6 in. (80.3 cm) |
| Diameter | 1.0 in. (2.5 cm) |
| Radome Material | Fiberglass |
| Mounting | Pole mount |
| RoHS Compliance | Yes |
| Shock and Vibration | ETS 300 019-1-4 |
| Wind Rating | 100 mph (161 kph) sustained, 165 mph (265 kph) gusts |
