WS-C4900M
Артикул:
₴ 533,439.00
Cisco Catalyst 4900M 8-port base system
The Cisco WS-C4900M Switch is a high-performance, reliable switch designed for deployment in data centers and wiring closets. This switch is known for its scalability and flexibility, making it ideal for various networking environments. With advanced security features and robust hardware, the Cisco WS-C4900M ensures seamless and efficient network operations.
WS-C4900M Specifications |
|
|
Switching capacity |
320 Gbps |
|
Throughput |
250 mpps for IPv4 125 mpps for IPv6 |
|
IPv6 support |
In hardware |
|
Height |
2RU |
|
Modular half-card slots |
2 |
|
Maximum 10/100/1000 Ports |
40 |
|
Maximum 10 Gigabit Ethernet (RJ-45) ports |
16 |
|
Maximum 10 Gigabit Ethernet (fiber) ports |
24 |
|
Maximum Gigabit Ethernet (fiber) ports |
32 (Cisco TwinGig Converter Module) |
|
Cisco TwinGig Converter Module support |
Yes (half cards only) |
|
Uplink optic types |
Eight X2 (10 Gigabit Ethernet) optics, 8 SFP+ (using OneX) |
|
Multilayer switching |
IP Base and Enterprise Services options |
|
Shared buffer |
17.5 MB |
|
CPU |
1.3 GHz |
|
Synchronous Dynamic RAM (SDRAM) |
512 MB |
|
Active VLANs |
4096 |
|
Multicast entries |
70,000 for IPv4 35,000 for IPv6 |
|
Per VLAN Spanning Tree (PVST) Protocol and VLAN IDs |
4096 |
|
Spanning Tree Protocol instances |
4094 |
|
Switched Virtual Interfaces (SVIs) |
4096 |
|
Security and quality-of-service (QoS) hardware entries |
128,000 |
|
MAC addresses |
55,000 |
|
Switched Port Analyzer (SPAN) |
8 ingress and 8 egress |
|
USB port |
Yes |
|
Compact flash memory support |
Yes |
|
System reset button |
Yes |
|
Minimum software requirement |
Cisco IOS Software Release 12.2(46)SG or later |
|
Dimension (H x W x D [mm]) |
3.5 (89) x 17.2 (437) x 17.9 (455) |
|
Weight |
Cisco Catalyst 4900M 8-port base unit plus fan (no power supply): 25.0 lb (11.3 kg) Cisco Catalyst 4900M 8-port base unit plus fan and 1 AC power supply: 29.5 lb (13.4 kg) |
