C9400-PWR-2100AC
Артикул:
₴ 70,104.00
Cisco Catalyst 9400 Series Platinum Rated 2100W AC Power Supply
Cisco Catalyst 9400 Series 2100W AC Power Supply. There are three modes of operation supported by Cisco Catalyst 9400 power supplies. In all the modes the power supplies can be of type whether AC or DC.
C9400-PWR-2100AC Specifications |
|
|
Power Supply |
2100W AC |
|
Integrated PoE |
Yes |
|
Input current (rated) |
● 10.4A at 100 VAC
● 10.4A at 200 VAC
|
|
Input voltage |
100 to 240 VAC (±10% for full range) |
|
Output current (data) |
● 55V at 38.21/17.09A
(230/115VAC ranges)
● 3.3V at 3.0A
|
|
Output power (N+N) redundant mode |
(2102W x N)/2 + 10W (3.3V standby) for 230VAC range (940W x N)/2 + 10W (3.3V standby) for 115VAC range N = number of power supplies (N>1) |
|
Output power (N+1) redundant mode |
(2102W x (N-1)) + 10W (3.3V standby) for 230VAC range (940W x (N-1)) + 10W (3.3V standby) for 115VAC range N = number of power supplies (N>1) |
|
Output Power Combined mode |
(2102W x N) + 10W (3.3V standby) for 230VAC range (940W x N) + 10W (3.3V standby) for 115VAC range N = number of power supplies (N>1) |
|
Heat dissipation |
460 BTU/hr x N N = number of power supplies |
|
Holdup time |
20 ms |
|
Hot swappable |
Yes |
|
MTBF |
300,000 hours |
|
Minimum Software Requirement |
Cisco IOS XE Software Release 16.8.1 |
