SM-X-72FXS
Артикул:
₴ 622,863.00
72-port FXS double-wide service module
The Cisco SM-X-72FXS is a 72-port FXS double-wide service module designed to integrate seamlessly with Cisco Integrated Services Routers. Ideal for enterprises and service providers requiring analog phone connectivity and reliable telephony infrastructure, this module enhances voice communication while ensuring scalability and high performance.
SM-X-72FXS Specifications | |
| Brand | Cisco |
| Model | SM-X-72FXS |
| Type | 72-port FXS double-wide service module |
| Ports | 72 FXS |
| Form Factor | Double-wide service module |
| Compatibility | Cisco ISR 4000 Series |
| Power Consumption | 50W typical |
| Voltage Range | 42.5V to 56V DC |
| Operating Temperature | 32??F to 104??F (0??C to 40??C) |
| Storage Temperature | -40??F to 158??F (-40??C to 70??C) |
| Operating Humidity | 10% to 90% non-condensing |
| Storage Humidity | 5% to 95% non-condensing |
| Regulatory Compliance | FCC, CE, UL |
| Dimensions | 1.5 x 14.4 x 7.3 inches |
| Software Support | Cisco IOS XE |
| Warranty | 1 year |
| Max Power Dissipation | 70W |
| Heat Dissipation | 238 BTU/hr |
| LEDs | Port status LEDs |
| MTBF | 1,000,000 hours |
| Connector Type | RJ-11 |
