NM-1T3/E3
Артикул:
₴ 1,518.00
One port T3/E3 network module Cisco Router Network Module
NM-1T3/E3 Specifications |
|
| Port Count | One port |
| Interface Type | T3/E3 |
| Compatible Routers | Cisco 2600, 3600, and 3700 series |
| Data Rate | Up to 34.368 Mbps (E3) / 44.736 Mbps (T3) |
| Protocols Supported | HDLC, PPP |
| Form Factor | Internal module |
| Full-Duplex | Yes |
| Connector Type | BNC |
| Clocking | Internal and external |
| Maximum Distance | 450 feet (internal clocking), 655 feet (external clocking) |
| Encapsulation Methods | Frame Relay, ATM, Transparent HDLC |
| Error Correction | BIP (Bit Interleaved Parity) |
| Redundancy Support | No (single module) |
| Installation Type | Plug and play |
| Environmental Operating Range | 32°F to 104°F (0°C to 40°C) |
| Storage Temperature Range | -4°F to 149°F (-20°C to 65°C) |
| Humidity Range (operating) | 10% to 85% non-condensing |
| Industry Standards | IEEE, ITU-T |
| Power Requirements | 5V DC, 1.8A |
| Dimensions (HxWxD) | 1.75 x 7.3 x 7.5 inches |
| Warranty | 1 year |
