HWIC-3G-HSPA

HWIC-3G-HSPA Specification

Product Number

HWIC-3G-HSPA

Product Description

3G HSPA Wireless WAN HWIC supporting GPRS/EDGE/UMTS/HSDPA/HSUPA (Global SKU)

External interfaces

• RJ-45 interface for use with third-party diagnostics and monitoring tools

• TNC RF port for antenna connection

• HWIC-3G-HSPA supports main and diversity antenna connector

Form factor

Single wide Cisco 3G WWAN HWIC form factor

Physical dimensions (H x W x D)

0.75 x 3.08 x 4.9 in. (1.9 x 7.8 x 12.4 cm)

Weight

0.24 lb (3.84 oz)

Subscriber Identity Module (SIM) card

SIM card socket; compliant with ISO-7816-2 (SIM mechanical)

Power

4.5W maximum

Supported platforms

Modular Cisco 1841, 1861, 1900, 2800, 2900, 3800 and 3900 Integrated Services Routers

Software compatibility

Modular Cisco 1841, 1861, 2800 and 3800 series Integrated Services Routers supported with the following Cisco IOS Releases:

• Cisco IOS Software feature set: IP Base IOS image

• HWIC-3G-HSPA supported with 15.0(1)M or later

Modular Cisco 1900,2900,and 3900 series Integrated Services Routers supported with Cisco IOS Software release :

• Cisco IOS Software feature set: Universal IOS image

• HWIC-3G-HSPA supported with 15.0(1)M1 or later

MIBs

• 3G MIB

• ENTITY MIB

• IF MIB

Network management and diagnostics

• In-band and out-of-band management using Telnet (Cisco IOS Software command-line interface [CLI]) and Simple Network Management Protocol (SNMP), including MIB II and other extensions

• Industry-standard 3G diagnostics and monitoring tools (QUALCOMM CDMA Air Interface Tester [CAIT] and Spirent Universal Diagnostic Monitor [UDM])

Modem information

• Modem form factor: Embedded Peripheral Component Interconnect (PCI) minicard

• HWIC-3G-HSPA: Sierra Wireless MC8790 (non-US market)
